medidor de flujo Electromagnetico Water Flow Meter RS485 Modbus
Product Description
Parameters | Aperture | 10-3200 |
| Installation Form | Integral or split |
| Lining | Chloroprene Rubber,PTFE |
| Material of Electrode | 316L,HC,HB,Titanium,Tantalum,Platiniridium |
| Medium | Conductive Liquid |
| Grade of Accuracy | 0.3 ,0.5, 1.0 |
| Pipe connection | Flange Connection |
| Temperature of Medium | Chloroprene Rubber:-10-60℃: PTFE:-10-120℃ |
| Category of Shielding | IP65, IP68 |
| Output Signal | 4-20mACurrent,Pulse, Warning beyond upper and lower limits |
| Communication | RS485 Protocol |
| Power Supply | 220VAC, 24VDC |
| lining | Main performance | Scope of application |
| F4(PTFE) polytetrafluoroet hylene | A plastic and chemical properties of the most stable, capable of boiling hydrochloric acid, sulfuric acid, nitric acid, and concentrated alkali and organic solvents. Not resistant to three chlorine fluoride, high temperature, high velocity fluid three chlorine trifluoride fluorine, oxygen, corrosion | Concentrated acid and other strong corrosive medium, medium health class |
| Chloroprene rubber | The elastic properties, tensile strength, wear resistance, corrosion resistance, low concentration of acid, alkali, salt, corrosion resistance and oxidation medium | Water, sewage, low wear of mud slurry |
| Polyurethane rubber | Strong wear resistance, corrosion resistance is poor | The slurry, coal slurry, slurry neutral strong wear |
Conventional caliber flow range( Large caliber Advisory )
Outline dimension
Application area
1. Drinking water supply, water supply, reservoir and pumping station etc.
2. Chemical acid, lye, conductive solution, cooling fluid, additives etc.
3. Drink water, beer, wine, alcohol, milk, yogurt, fruit juice, syrup, blood etc.
4. Refrigeration / air conditioning and refrigeration thermal measurement, or heat energy.
5. Sewage, industrial sewage discharge, sewage etc.
Order sheet
| Name | Specification code | Explanation |
| Electrode form | 1 |
|
|
Electrode material | 0 | Stainless steel(316L) |
| 1 | Platinum Pt | |
| 2 | Hastelloy B(HB) | |
| 3 | Tantalum Ta | |
| 4 | Titanium Ti | |
| 5 | Hastelloy C(HC) | |
|
Lining material | 3 | Chloroprene rubber |
| 4 | Polyurethane rubber | |
| 5 | F4(PTFE) polytetrafluoroethylene | |
| 6 | F46(FEP)polyperfluoroethylene-propylene | |
|
Rated pressure(MPa) | 4.0 | DN10-80 |
| 1.6 | DN100-150 | |
| 1.0 | DN200-1000 | |
| 0.6 | DN1100-2000 | |
| 0.25 | DN2200 | |
|
Operating temperature | E | <80℃ |
| H | <120℃ | |
| Grade of protection | 0 | IP65 |
| 1 | IP68 | |
| Converter type | 0 | Integral type |
| 1 | Split type | |
| Case material | 0 | Carbon steel |
| 1 | Stainless steel | |
| Instrument flange | 0 | Carbon steel |
| 1 | Stainless steel | |
| Power supply source | 0 | 220VAC |
| 1 | 24VDC |
